Fujitsu PRIMERGY RX2540 M6 Upgrade And Maintenance Manual

▶
Connect all cables to the system board.
For the cable plans, see "Appendix B" on page 571.
Concluding steps
▶
If applicable, install the TPM, see "Installing the TPM" on page
481.
▶
If applicable, install the Dual microSD 64GB Enterprise, see "Installing the
Dual microSD 64GB Enterprise" on page 506.
▶
If applicable, install all M.2 SSDs, see "Installing the M.2 SSD" on page 498.
▶
Install the iRMC microSD card, see "Installing the iRMC microSD card" on
page 492.
Ensure that you install the iRMC microSD card that was installed in
the system board before the replacement.
▶
If applicable, install all expansion cards, see "Installing the expansion card"
on page
256
.
▶
"Installing the cross bar" on page 81.
▶
"Installing the fan cage" on page 76.
▶
Install all riser modules, see "Installing a riser module" on page 72.
▶
For a system with air cooling, proceed as follows:
▶
Install all memory modules, see "Installing a memory module" on
page 338.
Ensure that you reinstall each memory module in the slot it was
located before the replacement.
CAUTION
In case of Optane PMem modules are not reinstalled in the right
slots, data can be lost!
▶
If applicable, install all dummy memory modules, see "Installing a
memory dummy module" on page
343
.
System board and components
RX2540 M6 Upgrade and Maintenance Manual 529

Fujitsu PRIMERGY RX2540 M6 Specifications

General

Memory Slots	32 DIMM slots
Form Factor	2U rack server
Processor	Intel Xeon Scalable Processors (3rd generation)
Storage	Up to 24 x 2.5" or 12 x 3.5" drives
RAID Support	RAID 0, 1, 5, 6, 10
Network	4 x 1GbE ports (onboard), optional 10/25GbE
Power Supply	800 W, 1200 W, 1600 W
Expansion Slots	Up to 8x PCIe Gen4 slots
Operating System Support	Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, VMware
Management	iRMC S5
