Operation Manual – Link Aggregation
H3C S3100 Series Ethernet Switches Chapter 1 Link Aggregation Configuration
1-13
[Sysname-Ethernet1/0/2] quit
[Sysname] interface Ethernet1/0/3
[Sysname-Ethernet1/0/3] port link-aggregation group 1
2) Adopting static LACP aggregation mode
# Create static aggregation group 1.
<Sysname> system-view
[Sysname] link-aggregation group 1 mode static
# Add Ethernet1/0/1 through Ethernet1/0/3 to aggregation group 1.
[Sysname] interface Ethernet1/0/1
[Sysname-Ethernet1/0/1] port link-aggregation group 1
[Sysname-Ethernet1/0/1] quit
[Sysname] interface Ethernet1/0/2
[Sysname-Ethernet1/0/2] port link-aggregation group 1
[Sysname-Ethernet1/0/2] quit
[Sysname] interface Ethernet1/0/3
[Sysname-Ethernet1/0/3] port link-aggregation group 1
3) Adopting dynamic LACP aggregation mode
# Enable LACP on Ethernet1/0/1 through Ethernet1/0/3.
<Sysname> system-view
[Sysname] interface Ethernet1/0/1
[Sysname-Ethernet1/0/1] lacp enable
[Sysname-Ethernet1/0/1] quit
[Sysname] interface Ethernet1/0/2
[Sysname-Ethernet1/0/2] lacp enable
[Sysname-Ethernet1/0/2] quit
[Sysname] interface Ethernet1/0/3
[Sysname-Ethernet1/0/3] lacp enable
Caution:
The three LACP-enabled ports can be aggregated into one dynamic aggregation group
to implement load sharing only when they have the same basic configuration (such as
rate, duplex mode, and so on).
