Operation Manual – Mirroring
H3C S3100 Series Ethernet Switches Chapter 1 Mirroring Configuration
1-8
Operation Command Description
Configure the current
port as trunk port
port link-type trunk
Required
By default, the port type
is Access.
Configure trunk port to
permit packets from the
remote-probe VLAN
port trunk permit vlan
remote-probe-vlan-id
Required
Return to system view
quit
—
Create a remote
destination mirroring
group
mirroring-group group-id
remote-destination
Required
Configure the
destination port for the
remote destination
mirroring group
mirroring-group group-id
monitor-port monitor-port
Required
Configure the
remote-probe VLAN for
the remote destination
mirroring group
mirroring-group group-id
remote-probe vlan
remote-probe-vlan-id
Required
When configuring a destination switch, note that:
z The destination port of remote port mirroring cannot be a member port of an
aggregation group, or a port enabled with LACP or STP.
z Only an existing static VLAN can be configured as the remote-probe VLAN. To
remove a remote-probe VLAN, you need to restore it to a normal VLAN first. A
remote port mirroring group gets invalid if the corresponding remote port mirroring
VLAN is removed.
1.2.3 Displaying Port Mirroring
After the above configurations, you can execute the display commands in any view to
view the mirroring running information, so as to verify your configurations.
Table 1-7 Display configuration of mirroring
Operation Command Description
Display port mirroring
configuration
display mirroring-group
{ group-id | all | local |
remote-destination |
remote-source }
Available in any view
