Operation Manual – HWPing
H3C S3100 Series Ethernet Switches Chapter 1 HWPing Configuration
1-26
6 15653 1 0 2000-04-03 03:59:21.2
7 9792 1 0 2000-04-03 03:59:05.5
8 9794 1 0 2000-04-03 03:58:55.6
9 9891 1 0 2000-04-03 03:58:45.8
10 3245 1 0 2000-04-03 03:58:35.9
For detailed output description, see the corresponding command manual.
 Note:
If you are downloading a file from the server, you do not need to specify an FTP
operation type. For details, see section
1.2.2 I. 3).
1.3.4 HTTP Test
I. Network requirements
An H3C S3100 series Ethernet switch serves as the HWPing client, and a PC serves as
the HTTP server. Perform a HWPing HTTP test between the switch and the HTTP
server to test the connectivity and the time required to download a file from the HTTP
server after the connection to the server is established.
II. Network diagram
Figure 1-5 Network diagram for the HTTP test
III. Configuration procedure
z Configure HTTP Server:
Use Windows 2003 Server as the HTTP server. For HTTP server configuration, refer to
the related instruction on Windows 2003 Server configuration.
z Configure HWPing Client (Switch A):
# Enable the HWPing client.
<Sysname> system-view
[Sysname] hwping-agent enable
# Create a HWPing test group, setting the administrator name to "administrator" and
test tag to "HTTP".
