Operation Manual – PoE-PoE Profile
H3C S3100 Series Ethernet Switches Chapter 2 PoE Profile Configuration
2-3
Table 2-2 Display the PoE profile configuration
Operation Command Description
Display the detailed
information about the PoE
profiles created on the
switch
display poe-profile { all-profile |
interface interface-type
interface-number | name
profile-name }
Available in any
view
2.4 PoE Profile Configuration Example
2.4.1 PoE Profile Application Example
I. Network requirements
Switch A is an S3100 series Ethernet switch supporting PoE.
Ethernet 1/0/1 through Ethernet 1/0/10 of Switch A are used by users of group A, who
have the following requirements:
z The PoE function can be enabled on all ports in use.
z Signal mode is used to supply power.
z The PoE priority for Ethernet 1/0/1 through Ethernet 1/0/5 is Critical, whereas the
PoE priority for Ethernet 1/0/6 through Ethernet 1/0/10 is High.
z The maximum power for Ethernet 1/0/1 through Ethernet 1/0/5 ports is 3,000 mW,
whereas the maximum power for Ethernet 1/0/6 through Ethernet 1/0/10 is 15,400
mW.
Based on the above requirements, two PoE profiles are made for users of group A.
z Apply PoE profile 1 for Ethernet 1/0/1 through Ethernet 1/0/5;
z Apply PoE profile 2 for Ethernet 1/0/6 through Ethernet 1/0/10.
