Operation Manual – Login
H3C S3100 Series Ethernet Switches Chapter 3 Logging in through Telnet
3-14
[Sysname-ui-vty0] protocol inbound telnet
# Set the maximum number of lines the screen can contain to 30.
[Sysname-ui-vty0] screen-length 30
# Set the maximum number of commands the history command buffer can store to 20.
[Sysname-ui-vty0] history-command max-size 20
# Set the timeout time to 6 minutes.
[Sysname-ui-vty0] idle-timeout 6
3.5 Telnetting to a Switch
3.5.1 Telnetting to a Switch from a Terminal
1) Assign an IP address to VLAN-interface 1 of the switch (VLAN 1 is the default
VLAN of the switch).
z Connect the serial port of your PC/terminal to the Console port of the switch, as
shown in
Figure 3-4
Figure 3-4 Diagram for establishing connection to a Console port
z Launch a terminal emulation utility (such as Terminal in Windows 3.X or
HyperTerminal in Windows 95/Windows 98/Windows NT/Windows 2000/Windows
XP) on the PC terminal, with the baud rate set to 9,600 bps, data bits set to 8,
parity check set to none, and flow control set to none.
z Turn on the switch and press Enter as prompted. The prompt (such as <H3C>)
appears, as shown in the following figure.
