Operation Manual – Stack-Cluster
H3C S3100 Series Ethernet Switches Chapter 1 Stack
1-2
z When adding a switch joins in a stack, the main switch automatically assigns an IP
address to it.
z The main switch automatically adds any switches that are newly connected to the
stack through their stack ports to the stack.
1.2 Main Switch Configuration
The main switch configuration includes:
z Configuring the IP Address Pool and Creating the Stack
z Maintaining Slave Switches
1.2.1 Configuring the IP Address Pool and Creating the Stack
Follow these steps to configure the IP address pool and creating the stack:
Operation Command Description
Enter system view
system-view
—
Configure an IP
address pool for a
stack
stacking ip-pool
from-ip-address
ip-address-number
[ ip-mask ]
Required
from-ip-address: Start address of the
IP address pool.
ip-address-number: Number of the IP
addresses in the IP addresses pool. A
pool contains 16 addresses by default.
ip-mask: Mask of the IP address pool.
By default, the IP addresses pool is not
configured.
Create a stack
stacking enable
Required
Note:
Remove the IP address configured for the existing Layer 3 interface first if you want to
cancel the stack-related configuration, otherwise, IP address conflicts may occur.
As for the stack-related configurations performed on a main switch, note that:
z After a stack is created, the main switch automatically adds the switches
connected to its stack ports to the stack.
z If a stack port connection is disconnected, the corresponding slave switch quits
the stack automatically.
z The IP address pool of an existing stack cannot be modified.
z To add a switch to a stack successfully, make sure the IP address pool contains at
least one unoccupied IP address.
