Operation Manual – VLAN-VPN
H3C S3100 Series Ethernet Switches Chapter 1 VLAN-VPN Configuration
1-5
1.3 Displaying and Maintaining VLAN-VPN Configuration
To do... Use the command... Remarks
Display the VLAN-VPN
configurations of all the
ports
display port vlan-vpn
Available in any view
1.4 VLAN-VPN Configuration Example
1.4.1 Transmitting User Packets through a Tunnel in the Public Network by
Using VLAN-VPN
I. Network requirements
As shown in Figure 1-4, Switch A and Switch B are both S3100 series switches. They
connect the users to the servers through the public network.
z PC users and PC servers are in VLAN 100 created in the private network, while
terminal users and terminal servers are in VLAN 200, which is also created in the
private network. The VLAN VPN connection is established in VLAN 1040 of the
public network.
z Switches of other vendors’ are used in the public network. They use the TPID
value 0x9200.
z Employ VLAN-VPN on Switch A and Switch B to enable the PC users and PC
servers to communicate with each through a VPN, and employ VLAN-VPN on
Switch A and Switch B to enable the Terminal users and Terminal servers to
communicate with each other through a VPN.
