H3C S3100 8C SI User Manual

Operation Manual – Login
H3C S3100 Series Ethernet Switches
Chapter 5 Logging in through the Web-based
Network Management System
5-1
Chapter 5 Logging in through the Web-based
Network Management System
5.1 Introduction
An S3100 Ethernet switch has a Web server built in. It enables you to log into an S3100
Ethernet switch through a Web browser and then manage and maintain the switch
intuitively by interacting with the built-in Web server.
To log into an S3100 Ethernet switch through the built-in Web-based network
management system, you need to perform the related configuration on both the switch
and the PC operating as the network management terminal.
Table 5-1 Requirements for logging into a switch through the Web-based network
management system
Item Requirement
The VLAN interface of the switch is assigned an IP
address, and the route between the switch and the Web
network management terminal is reachable. (Refer to the
IP Address Configuration – IP Performance Configuration
and Routing Protocol parts for related information.)
Switch
The user name and password for logging into the
Web-based network management system are configured.
IE is available.
PC operating as the
network management
terminal
The IP address of the VLAN interface of the switch, the
user name, and the password are available.
5.2 Establishing an HTTP Connection
1) Assign an IP address to VLAN-interface 1 of the switch (VLAN 1 is the default
VLAN of the switch). See section
3.5.1 "Telnetting to a Switch from a Terminal" for
related information.
2) Configure the user name and the password on the switch for the Web network
management user to log in.
# Create a Web user account, setting both the user name and the password to “admin”
and the user level to 3.
<Sysname> system-view
[Sysname] local-user admin
[Sysname-luser-admin] service-type telnet level 3
