Operation Manual – QoS-QoS Profile
H3C S3100 Series Ethernet Switches Chapter 1 QoS Configuration
1-37
Operation Command Description
Display traffic shaping
configuration of a port or all the
ports
display qos-interface
{ interface-type
interface-number | unit-id }
traffic-shape
Display traffic accounting
configuration of a port or all the
ports
display qos-interface
{ interface-type
interface-number | unit-id }
traffic-statistic
Display traffic mirroring
configuration of a port or all the
ports
display qos-interface
{ interface-type
interface-number | unit-id }
mirrored-to
Display the configuration of traffic
mirroring, traffic policing, priority
marking, traffic redirecting, or
traffic accounting performed for all
the packets
display qos-global { all |
mirrored-to | traffic-limit |
traffic-priority |
traffic-redirect |
traffic-statistic }
Display the configuration of traffic
mirroring, traffic policing, priority
marking, traffic redirecting, or
traffic accounting performed for
packets of a VLAN
display qos-vlan [ vlan-id ]
{ all | mirrored-to | traffic-limit
| traffic-priority |
traffic-redirect |
traffic-statistic }
Display the configuration of traffic
mirroring, traffic policing, priority
marking, traffic redirecting, or
traffic accounting performed for
packets of a port group
display qos-port-group
[ group-id ] { all | mirrored-to |
traffic-limit | traffic-priority |
traffic-redirect |
traffic-statistic }
1.5 QoS Configuration Example
1.5.1 Configuration Example of Traffic Policing
I. Network requirement
An enterprise network connects all the departments through an S3100-EI Ethernet
switch. The R&D department belongs to the network segment 192.168.1.0/24 and
connects to the switch through Ethernet 1/0/1; the marketing department belongs to the
network segment 192.168.2.0/24 and connects to the switch through Ethernet 1/0/2.
Configure traffic policing to satisfy the following requirements:
z Set the maximum rate of outbound IP packets sourced from the marketing
department to 64 kbps. Drop the packets exceeding the rate limit.
z Set the maximum rate of outbound IP packets sourced from the R&D department
to 128 kbps. Drop the packets exceeding the rate limit.
