Operation Manual – HWPing
H3C S3100 Series Ethernet Switches Chapter 1 HWPing Configuration
1-2
1.1.2 Test Types Supported by HWPing
Table 1-1 Test types supported by HWPing
Supported test types Description
ICMP test
DHCP test
FTP test
HTTP test
DNS test
SNMP test
For these types of tests, you need to configure
HWPing client and corresponding servers.
Jitter test
Tcppublic test
TCP test
Tcpprivate test
Udppublic test
UDP test
Udpprivate test
z These types of tests need the cooperation of
HWPing client and HWPing Server.
z Do not perform a TCP, UDP or jitter test on a
well-known port (ports with a number ranging from
1 to 1023) or on a port with a port number greater
than 50000. Otherwise, your HWPing test may fail
or the service corresponding to the well-known
port may become unavailable.
Caution:
H3C S3100-SI series Ethernet switches do not support HWPing DNS tests.
1.1.3 HWPing Test Parameters
You need to configure corresponding test parameters for each type of HWPing test.
HWPing test parameters can be configured on HWPing client only. For the
configurations on HWPing client, refer to section
1.2.2 HWPing Client Configuration.
Table 1-2 HWPing test parameters
Test parameter Description
Destination address
(destination-ip)
For TCP/UDP/jitter test, you must specify a
destination IP address, and the destination
address must be the IP address of a
TCP/UDP/UDP listening service configured on
the HWPing server.
Destination port
(destination-port)
For tcpprivate/udpprivate/jitter test, you must
specify a destination port number, and the
destination port number must be the port
number of a TCP or UDP listening service
configured on the HWPing server.
