Operation Manual – QoS-QoS Profile
H3C S3100 Series Ethernet Switches Chapter 1 QoS Configuration
1-26
[Sysname] traffic-limit vlan 2 inbound ip-group 2000 128 exceed remark-dscp
56
1.4.5 Configuring Traffic Shaping
 Note:
Only H3C S3100-EI series switches support this configuration.
Refer to section
Traffic Policing and Traffic Shaping for information about traffic
shaping.
I. Configuration prerequisites
z The maximum traffic rate and the burst size are determined.
z The port where traffic shaping is to be configured is determined.
II. Configuration procedure
Table 1-22 Configure traffic shaping
Operation Command Description
Enter system view
system-view
—
Enter Ethernet port
view
interface interface-type
interface-number
—
Configure traffic
shaping
traffic-shape queue
queue-id max-rate
burst-size
Required
Traffic shaping is not enabled
by default.
III. Configuration examples
# Perform traffic shaping for all the traffic to be transmitted through Ethernet 1/0/1, with
the maximum traffic rate being 640 kbps and the burst size being 16 KB.
<Sysname> system-view
[Sysname] interface Ethernet1/0/1
[Sysname-Ethernet1/0/1] traffic-shape 640 16
1.4.6 Configuring Port Rate Limiting
Refer to section Port Rate Limiting for information about port rate limiting. Note that, the
target-rate argument is committed information rate (CIR).
