Operation Manual – SNMP-RMON
H3C S3100 Series Ethernet Switches Chapter 1 SNMP Configuration
1-9
Table 1-7 Display SNMP
Operation Command Description
Display the SNMP information
about the current device
display snmp-agent sys-info
[ contact | location | version ]*
Display SNMP packet statistics
display snmp-agent statistics
Display the engine ID of the
current device
display snmp-agent
{ local-engineid |
remote-engineid }
Display group information about
the device
display snmp-agent group
[ group-name ]
Display SNMP user information
display snmp-agent
usm-user [ engineid engineid |
username user-name | group
group-name ]
Display Trap list information
display snmp-agent trap-list
Display the currently configured
community name
display snmp-agent
community [ read | write ]
Display the currently configured
MIB view
display snmp-agent mib-view
[ exclude | include | viewname
view-name ]
Available in
any view.
1.6 SNMP Configuration Examples
1.6.1 SNMP Configuration Examples
I. Network requirements
z An NMS and Switch A (SNMP agent) are connected through the Ethernet. The IP
address of the NMS is 10.10.10.1 and that of the VLAN interface on Switch A is
10.10.10.2.
z Perform the following configuration on Switch A: setting the community name and
access permission, administrator ID, contact and switch location, and enabling the
switch to sent trap messages.
Thus, the NMS is able to access Switch A and receive the trap messages sent by
Switch A.
