Operation Manual – VLAN
H3C S3100 Series Ethernet Switches Chapter 2 VLAN Configuration
2-8
2.2.6 Troubleshooting Ethernet Port Configuration
Symptom: Fail to configure the default VLAN ID of an Ethernet port.
Solution: Take the following steps.
z Use the display interface or display port command to check if the port is a trunk
port or a hybrid port.
z If the port is not a trunk or hybrid port, configure it to be a trunk or hybrid port.
z Configure the default VLAN ID of the port.
 Note:
For information about the display interface command, refer to Port Basic
Configuration in this manual.
2.3 Configuring a Protocol-Based VLAN
 Note:
The contents of this section are only applicable to the S3100-EI series among S3100
series switches.
2.3.1 Protocol-Based VLAN Configuration Task List
Complete these tasks to configure protocol-based VLAN:
Task Remarks
Configuring a Protocol Template for a Protocol-Based VLAN Required
Associating a Port with a Protocol-Based VLAN Required
Displaying Protocol-Based VLAN Configuration Optional
2.3.2 Configuring a Protocol Template for a Protocol-Based VLAN
I. Configuration prerequisites
Create a VLAN before configuring the VLAN as a protocol-based VLAN.
II. Configuration procedure
Follow these steps to configure the protocol template for a VLAN:
