Operation Manual – SSH
H3C S3100 Series Ethernet Switches Chapter 1 SSH Configuration
1-22
From the category on the left of the window, select Connection/SSH/Auth. The
following window appears.
Figure 1-9 SSH client configuration interface 3
Click Browse… to bring up the file selection window, navigate to the private key file and
click Open. If the connection is normal, a user will be prompted for a username. Once
passing the authentication, the user can log in to the server.
1.4.3 Configuring an SSH Client Assumed by an SSH2-Capable Switch
Table 1-14 Complete the following tasks to configure an SSH client that is assumed by
an SSH2-capable switch:
Task Remarks
Configuring the SSH client for publickey
authentication
z Not necessary when the
authentication mode is password.
z Required when the authentication
mode is publickey.
Configuring whether first-time
authentication is supported
Optional
Establishing the connection between the
SSH client and server
Required
To Next Page
