Operation Manual – Stack-Cluster
H3C S3100 Series Ethernet Switches Chapter 1 Stack
1-5
Operation Command Description
Display the stack
status information
on a slave switch
display stacking
Optional
The display command can be
executed in any view.
The displayed information indicates
that the local switch is a slave switch.
The information such as stack number
of the local switch, and the MAC
address of the main switch in the stack
is also displayed.
1.5 Stack Configuration Example
I. Network requirements
Connect Switch A, Switch B and Switch C with each other through their stack ports to
form a stack, in which Switch A acts as the main switch, while Switches B and C act as
slave switches.
Configure Switches B and Switch C through Switch A.
II. Network diagram
Figure 1-1 Network diagram for stack configuration
III. Configuration procedure
# Configure the IP address pool for the stack on Switch A.
<Sysname> system-view
[Sysname] stacking ip-pool 129.10.1.15 3
