H3C S3100 8C SI User Manual

Operation Manual – MSTP
H3C S3100 Series Ethernet Switches Chapter 1 MSTP Configuration
1-36
Table 1-27 Configure leaf nodes
Operation Description Related section
Enable MSTP
Required
To prevent network
topology jitter caused by
other related
configurations, you are
recommended to enable
MSTP after performing
other configurations.
Section
1.3.14 “Enabling
MSTP
”
Configure the MST region Required
Section
1.3.2
“Configuring an MST
Region
”
Configure the mode a port
recognizes and sends
MSTP packets
Optional
Section
1.3.5
“Configuring the Mode a
Port Recognizes and
Sends MSTP Packets
”
Configure the timeout
time factor
Optional
Section
1.3.10
“Configuring the Timeout
Time Factor
”
Configure the maximum
transmitting speed on the
current port
Optional
The default value is
recommended.
Section
1.3.11
“Configuring the
Maximum Transmitting
Speed on the Current
Port
”
Configure the current port
as an edge port
Optional
Section
1.3.12
“Configuring the Current
Port as an Edge Port
”
Configure the path cost
for a port
Optional
Section
1.4.7
“Configuring the Path
Cost for a Port
”
Configure the port priority Optional
Section
1.4.8
“Configuring Port Priority”
Specify whether the link
connected to a port is
point-to-point link
Optional
Section
1.3.13
“Specifying Whether the
Link Connected to a Port
Is Point-to-point Link
”
 Note:
In a network containing switches with both GVRP and MSTP enabled, GVRP packets
are forwarded along the CIST. In this case, if you want to broadcast packets of a
specific VLAN through GVRP, be sure to map the VLAN to the CIST when configuring
the MSTP VLAN mapping table (the CIST of a network is spanning tree instance 0).
