Operation Manual – QoS-QoS Profile
H3C S3100 Series Ethernet Switches Chapter 1 QoS Configuration
1-20
Table 1-12 Configure DSCP-precedence-to-local-precedence mapping table
Operation Command Description
Enter system view
system-view
—
Configure
DSCP-precedence-to-local-
precedence mapping table
qos
dscp-local-precedence-map
dscp-list : local-precedence
Required
Table 1-13 Configure IP-precedence-to-local-precedence mapping table
Operation Command Description
Enter system view
system-view
—
Configure
IP-precedence-to-loca
l-precedence mapping
table
qos
ip-precedence-local-precedence-map
ip0-map-local-prec ip1-map-local-prec
ip2-map-local-prec ip3-map-local-prec
ip4-map-local-prec ip5-map-local-prec
ip6-map-local-prec ip7-map-local-prec
Required
 Note:
The IP-precedence-to-local-precedence mapping table is not available on S3100-EI
series Ethernet switches.
III. Configuration example
z Configure the CoS-precedence-to-local-precedence mapping relationship as
follows: 0 to 0, 1 to 0, 2 to 1, 3 to 1, 4 to 2, 5 to 2, 6 to 3, and 7 to 3.
z Display the configuration.
Configuration procedure:
<Sysname> system-view
[Sysname] qos cos-local-precedence-map 0 0 1 1 2 2 3 3
[Sysname] display qos cos-local-precedence-map
cos-local-precedence-map:
cos(802.1p) : 0 1 2 3 4 5 6 7
local precedence(queue) : 0 0 1 1 2 2 3 3
