H3C S3100 8C SI User Manual

Operation Manual – NTP
H3C S3100 Series Ethernet Switches Chapter 1 NTP Configuration
1-5
III. Broadcast mode
Figure 1-4 Broadcast mode
IV. Multicast mode
Figure 1-5 Multicast mode
Table 1-1 describes how the above mentioned NTP modes are implemented on H3C
S3100 series Ethernet switches.
Table 1-1 NTP implementation modes on H3C S3100 series Ethernet switches
NTP implementation
mode
Configuration on S3100 series switches
Server/client mode
Configure the local S3100 Ethernet switch to work in the
NTP client mode. In this mode, the remote server serves
as the local time server, while the local switch serves as
the client.
Symmetric peer mode
Configure the local S3100 switch to work in NTP
symmetric peer mode. In this mode, the remote server
serves as the symmetric-passive peer of the S3100
switch, and the local switch serves as the
symmetric-active peer.
