Operation Manual – System Maintenance and Debugging
H3C S3100 Series Ethernet Switches
Chapter 1 Boot ROM and Host Software
Loading
1-4
3. Set XMODEM protocol parameter
0. Return to boot menu
Enter your choice(0-3):
Step 2: Press 3 in the above menu to download the Boot ROM using XModem. The
system displays the following setting menu for download baudrate:
Please select your download baudrate:
1.* 9600
2. 19200
3. 38400
4. 57600
5. 115200
0. Return
Enter your choice (0-5):
Step 3: Choose an appropriate baudrate for downloading. For example, if you press 5,
the baudrate 115200 bps is chosen and the system displays the following information:
Download baudrate is 115200 bps
Please change the terminal's baudrate to 115200 bps and select XMODEM protocol
Press enter key when ready
 Note:
If you have chosen 9600 bps as the download baudrate, you need not modify the
HyperTerminal’s baudrate, and therefore you can skip Step 4 and 5 below and proceed
to Step 6 directly. In this case, the system will not display the above information.
Following are configurations on PC. Take the HyperTerminal in Windows 2000 as an
example.
Step 4: Choose [File/Properties] in HyperTerminal, click <Configure> in the pop-up
dialog box, and then select the baudrate of 115200 bps in the Console port
configuration dialog box that appears, as shown in
Figure 1-1, Figure 1-2.
