Operation Manual – System Maintenance and Debugging

H3C S3100 Series Ethernet Switches

Chapter 1 Boot ROM and Host Software

1-11

 Note:

You can use one computer as both configuration device and FTP server.

Step 2: Run the FTP server program on the FTP server, configure an FTP user name

and password, and copy the program file to the specified FTP directory.

Step 3: Run the HyperTerminal program on the configuration PC. Start the switch. Then

enter the BOOT Menu.

At the prompt "Enter your choice(0-9):" in the BOOT Menu, press <6> or <Ctrl+U>, and

then press <Enter> to enter the Boot ROM update menu shown below:

Bootrom update menu:

1. Set TFTP protocol parameter

2. Set FTP protocol parameter

3. Set XMODEM protocol parameter

0. Return to boot menu

Enter your choice(0-3):

Step 4: Enter 2 in the above menu to download the Boot ROM using FTP. Then set the

following FTP-related parameters as required:

Load File name :switch.btm

Switch IP address :10.1.1.2

Server IP address :10.1.1.1

FTP User Name :Switch

FTP User Password :abc

Step 5: Press <Enter>. The system displays the following information:

Are you sure to update your bootrom?Yes or No(Y/N)

Step 6: Enter Y to start file downloading or N to return to the Boot ROM update menu. If

you enter Y, the system begins to download and update the program. Upon completion,

the system displays the following information:

Loading........................................done

Bootrom updating..........done!

z Loading host software

Follow these steps to load the host software:

Step 1: Select <1> in BOOT Menu and press <Enter>. The system displays the

following information:

1. Set TFTP protocol parameter

2. Set FTP protocol parameter

3. Set XMODEM protocol parameter

0. Return to boot menu
