Operation Manual – System Maintenance and Debugging
H3C S3100 Series Ethernet Switches Chapter 4 Device Management
4-7
The host software switch.bin and the Boot ROM file boot.btm of the switch are stored in
the directory switch on the PC. Use FTP to download the switch.bin and boot.btm files
from the FTP server to the switch.
II. Network diagram
Switch
PC
Network
1.1.1.12.2.2.2
Figure 4-1 Network diagram for FTP configuration
III. Configuration procedure
1) Configure the following FTP server–related parameters on the PC: an FTP user
with the username as switch and password as hello, who is authorized with the
read-write right on the directory Switch on the PC. The detailed configuration is
omitted here.
2) On the switch, configure a level 3 telnet user with the username as user and
password as hello. Authentication mode is by user name and password.
Note:
Refer to the “Login Operation” part of this manual for configuration commands and
steps about telnet user.
3) Execute the telnet command on the PC to log into the switch. The following
prompt appears:
<Sysname>
Caution:
If the Flash memory of the switch is not sufficient, delete the original applications before
downloading the new ones.
4) Initiate an FTP connection with the following command in user view. Enter the
correct user name and password to log into the FTP server.
<Sysname> ftp 2.2.2.2
Trying ...
Press CTRL+K to abort
