Operation Manual – VLAN-VPN
H3C S3100 Series Ethernet Switches Chapter 2
Selective QinQ Configuration
2-7
[SwitchB-Etherent1/0/11] port link-type hybrid
[SwitchB-Etherent1/0/11] port hybrid vlan 12 13 1000 1200 tagged
# Configure Ethernet1/0/12 as a hybrid port and configure VLAN 12 as its default VLAN .
Configure Ethernet 1/0/12 to remove VLAN tags when forwarding packets of VLAN 12
and VLAN 1000.
[SwitchB] interface Ethernet 1/0/12
[SwitchB-Etherent1/0/12] port link-type hybrid
[SwitchB-Etherent1/0/12] port hybrid pvid vlan 12
[SwitchB-Etherent1/0/12] port hybrid vlan 12 1000 untagged
[SwitchB-Ethernet1/0/12] quit
# Configure Ethernet 1/0/13 as a hybrid port and configure VLAN 13 as its default
VLAN . Configure Ethernet 1/0/13 to remove VLAN tags when forwarding packets of
VLAN 13 and VLAN 1200.
[SwitchB] interface Ethernet 1/0/13
[SwitchB-Etherent1/0/13] port link-type hybrid
[SwitchB-Etherent1/0/13] port hybrid pvid vlan 13
[SwitchB-Etherent1/0/13] port hybrid vlan 13 1200 untagged
After the above configuration, Switch B can forward packets of VLAN 1000 and VLAN
1200 to the corresponding servers through Ethernet 1/0/12 and Ethernet 1/0/13
respectively.
To make the packets from the servers be transmitted to the clients in the same way, you
need to configure the selective QinQ feature on SwitchB. The configuration on Switch B
is similar to that on Switch A and is thus omitted.
 Note:
z A selective QinQ-enabled device tags a user packet with an outer VLAN tag
regardless of the VLAN tag of the user packet, so there is no need to configure user
VLANs on the device.
z Make sure the packets of the default VLAN of a selective QinQ-enabled port are
permitted on both the local port and the port connecting to the public network.
