Operation Manual – Login
H3C S3100 Series Ethernet Switches Chapter 7 User Control
7-5
7.3.1 Prerequisites
The controlling policy against network management users is determined, including the
source IP addresses to be controlled and the controlling actions (permitting or denying).
7.3.2 Controlling Network Management Users by Source IP Addresses
Controlling network management users by source IP addresses is achieved by
applying basic ACLs, which are numbered from 2000 to 2999.
Follow these steps to control network management users by source IP addresses:
To do… Use the command… Remarks
Enter system view
system-view
—
Create a basic ACL
or enter basic ACL
view
acl number acl-number
[ match-order { auto | config } ]
As for the acl
number command,
the config keyword
is specified by
default.
Define rules for the
ACL
rule [ rule-id ] { deny | permit }
[ rule-string ]
Required
Quit to system view
quit
—
Apply the ACL while
configuring the
SNMP community
name
snmp-agent community { read |
write } community-name [ acl
acl-number | mib-view view-name ]*
Apply the ACL while
configuring the
SNMP group name
snmp-agent group { v1 | v2c }
group-name [ read-view read-view ]
[ write-view write-view ]
[ notify-view notify-view ] [ acl
acl-number ]
snmp-agent group v3 group-name
[ authentication | privacy ]
[ read-view read-view ] [ write-view
write-view ] [ notify-view
notify-view ] [ acl acl-number ]
Apply the ACL while
configuring the
SNMP user name
snmp-agent usm-user { v1 | v2c }
user-name group-name [ acl
acl-number ]
snmp-agent usm-user v3
user-name group-name [ [ cipher ]
authentication-mode { md5 | sha }
auth-password [ privacy-mode
{ des56 | aes128 } priv-password ] ]
[ acl acl-number ]
Required
According to the
SNMP version and
configuration
customs of NMS
users, you can
reference an ACL
when configuring
community name,
group name or
username. For the
detailed
configuration, refer to
SNMP-RMON for
more.
