Operation Manual – Smart Link-Monitor Link
H3C S3100 Series Ethernet Switches Chapter 2 Monitor Link Configuration
2-7
[SwitchA-Ethernet1/0/1] quit
[SwitchA] interface Ethernet 1/0/2
[SwitchA-Ethernet1/0/2] stp disable
# Return to system view.
[SwitchA-Ethernet1/0/2] quit
# Create Smart Link group 1 and enter Smart Link group view.
[SwitchA] smart-link group 1
# Configure Ethernet1/0/1 as the master port of the Smart Link group and Ethernet1/0/2
as the slave port.
[SwitchA-smlk-group1] port Ethernet 1/0/1 master
[SwitchA-smlk-group1] port Ethernet 1/0/2 slave
# Configure to send flush messages in VLAN 1.
[SwitchA-smlk-group1] flush enable control-vlan 1
2) Enable Monitor Link on Switch C and Switch D and enable the function of
processing flush messages received from VLAN 1. Perform the following
configuration on Switch C. The operation procedure on Switch D is the same as
that performed on Switch C.
# Enter system view.
<SwitchC> system-view
# Create Monitor Link group 1 and enter Monitor Link group view
[SwitchC] monitor-link group 1
# Configure Ethernet1/0/1 as the uplink port of the Monitor Link group and
Ethernet1/0/2 and Ethernet1/0/3 as the downlink ports.
[SwitchC-mtlk-group1] port Ethernet 1/0/1 uplink
[SwitchC-mtlk-group1] port Ethernet 1/0/2 downlink
[SwitchC-mtlk-group1] port Ethernet 1/0/3 downlink
# Return to system view. Enable the function of processing flush messages received
from VLAN 1 on Ethernet1/0/2 and Ethernet1/0/3.
[SwitchC-mtlk-group1] quit
[SwitchC] smart-link flush enable control-vlan 1 port Ethernet 1/0/2 to
Ethernet 1/0/3
3) Enable the function of processing flush messages received from VLAN 1 on
Ethernet 1/0/10 and Ethernet 1/0/11 of Switch E.
# Enter system view.
<SwitchE> system-view
# Enable the function of processing flush messages received from VLAN 1 on Ethernet
1/0/10 and Ethernet 1/0/11.
