Configuring the Data Link Layer Protocol for E1, T1, and Serial Interfaces

Configuring the Logical Interface

Table 6-6 lists the Frame Relay counters, the possible settings, and the polls

that each one controls.

Table 6-6. Frame Relay Counters

You can use the no command to return counters to their default settings.

Frame Relay Counter Possible

Settings

Default

Setting

Description

frame-relay lmi-n391dce <polls> 1-255 6 Configure how many link integrity polls occur

in between the full-status polls. Configure this

setting for the DCE endpoint.

frame-relay lmi-n391dte <polls> 1-255 6 Configure how many link integrity polls occur

between the full status polls. Configure this

setting for the DTE endpoint.

frame-relay lmi-n392dce <threshold> 1-10 3 Configure an error threshold number for the

DCE. If the error threshold is met, the signaling

status is changed to down, which indicates a

service-affecting condition. This condition is

cleared after this number of consecutive

error-free N393 events are received.

frame-relay lmi-n392dte <threshold> 1-10 3 Configure an error threshold number for the

DTE. If the error threshold is met, the signaling

status is changed to down, which indicates a

service-affecting condition. This condition is

cleared after this number of consecutive

error-free N393 events are received.

frame-relay lmi-n393dce <counter> 1-10 4 Configure the LMI- monitored event counter

for the DCE endpoint.

frame-relay lmi-n393dte <counter> 1-10 4 Configure the LMI- monitored event counter

for the DTE endpoint.

frame-relay lmi-t391dte <seconds> 5-30 seconds 10 seconds Set the T391 signal-polling timer for the DTE

endpoint.

frame-relay lmi-t392dce <seconds> 5-30 seconds 10 seconds Set the T392 polling-verification timer for the

DCE endpoint.
