11-30
IP Routing—Configuring Static Routes
Troubleshooting Static Routing
Figure 11-10. Clearing Routes
For example, your router has the routes in the routing table shown in Figure
11-10. The routes to 192.168.65.0 /24 and 172.168.0.0 /16 are faulty and you want
to clear them. The first is a learned route, so you enter:
ProCurve# clear ip route 192.168.65.0 /24
The second is a static route, so you move to the global configuration mode
context and enter:
ProCurve(config)# no ip route 172.168.0.0 /16 ppp 1
ProCurve#show ip route
Codes: C - connected, S - static, R - RIP, O - OSPF, B - BGP
IA - OSPF inter area, N1 - OSPF NSSA external type 1
N2 - OSPF NSSA external type 2, E1 - OSPF external type 1
E2 - OSPF external type 2
Gateway of last resort 192.168.128.1
C 10.1.1.0/30 is directly connected, ppp 1
C 10.1.1.1/32 is directly connected, ppp 1
C 10.2.2.0/30 is directly connected, ppp 2
C 10.2.2.1/32 is directly connected, ppp 2
S 172.16.0.0/16 [1/0] via 10.1.1.1, ppp 1
R 172.16.3.0/24 [120/1] via 10.1.1.1, ppp 1
R 172.16.4.0/24 [120/1] via 10.1.1.1, ppp 1
O 192.168.65.0/24 [110/51] via 10.2.2.1, ppp 2
C 192.168.128.0/24 is directly connected, eth 0/1
C 192.168.129.0/24 is directly connected, eth 0/2
Faulty route
Misconfigured
route
