Stop settings
Field Description
Stop trigger state
If the trigger is inactive, a gray icon is displayed.
If the trigger is waited for, a green/gray icon is displayed.
If the trigger has occured, a green icon is displayed.
Stop trigger
Determines the stop trigger type:
● No Trigger: The trigger is deactivated. The sampling is either
stopped manually via the Deactivate button or if the measure
time elapses depending on Stop measure time setting.
● Mold Close: The trigger is set on mold close movements..
● Mold Open: The trigger is set on mold open movements.
● Injection: The trigger is set on injection movements.
● Plast: The trigger is set on plasticize movements.
● Variable: The trigger is set based on a customer variable.
Use falling edge
Per default, the trigger is set when the movement starts or the
custom variable is set to TRUE. If Use falling edgeis set to TRUE,
the trigger is set when the movement stops or the custom variable
is set to FALSE.
Stop counter
The number of stop triggers that have to occur before the trigger
action is performed and the recording is stopped.
Stop trigger delay
The delay time that has to elapse between the stop trigger event
and the recording is stopped.
Stop measure time
When set to TRUE, this parameter stops the recording when the
configured Measure time is elapsed. This enables the user to only
use a start trigger and sample for a defined amount of time.
Buttons
Field Description
Activate/Deactivate
Activates the scope measurement. Before a
measurement is activated, a valid configura-
tion file containing a list of variables to sample
has to be loaded first. Depending on the set-
tings, the start trigger is waited for or the sam-
pling is started immediately.
Deactivation deactivates a running sampling
process manually. If sampling is currently in
progress, the recording is stopped, the files are
saved and exported to USB.
Select
Opens a dialog to select the active scope con-
figuration. A set of predefined configurations
for each functional unit (e. g. inject, mold, ejec-
tor or heating) is provided.
KePlast.HMI.KVB Description of the operating masks
© KEBA 2016
User's manual V3.05 183
