Issue 8.0 June 2002 xix
Figures
3-19 Power Distribution and Fuse Panel 3-35
3-20 Repeater Shelf — System Controller (Without
Circuit Pack Cover) 3-36
3-21 Interconnection Panel (Repeater Shelf — System
Controller) 3-39
3-22 User Panel (FT-2000 OC-48 Repeater Shelf) for
Miscellaneous Mounting Only 3-41
3-23 Repeater Shelf — System Controller with Covers
(FT-2000 OC-48 Repeater Bay) 3-42
3-24 Repeater Shelf — System Controller with Covers
(FT-2000 OC-48 Repeater Shelf) 3-43
3-25 FT-2000 OC-48 Dual ADR Terminal for Two-Fiber
Rings (D-Bay) 3-46
3-26 FT-2000 OC-48 D-Bay Power Distribution and
Fuse Panel 3-47
3-27 Low-Speed Shelf — System Controller (Without
Circuit Pack Cover) — ED6G999-31, G5 3-48
3-28 Low-Speed Shelf — System Controller (Without
Circuit Pack Cover) — ED6G999-32, G3 3-49
3-29 Interconnection Panel (Low-Speed Shelf - System
Controller)—ED6G999-31,G5 3-54
3-30 User Panel (Enhanced) 3-55
3-31 Low-Speed Shelf - System Controller (with Covers) 3-56
3-32 Condensed High-Speed Shelf (Without Circuit
Pack Cover) 3-59
3-33 Interconnection and Filter Panel (Condensed
High-Speed Shelf) 3-62
4Power
4-1 Bay Power Distribution 4-2
4-2 Miscellaneously-Mounted FT-2000 OC-48
Repeater Shelf Power Distribution 4-3
4-3 Shelf Power Distribution 4-4
4-4 Circuit Pack Power Distribution 4-5
