xviii Issue 8.0 June 2002
Figures
2-22 Gateway Network Element Application
(Releases 4.1 and 5) 2-46
2-23 Gateway Network Element Application (Release 6
and Later) 2-47
3 Platform Descriptions
3-1 FT-2000 OC-48 Add/Drop-Rings Terminal for
Two-Fiber Rings (E-Bay) 3-3
3-2 Power Distribution and Fuse Panel 3-4
3-3 Low-Speed Shelf — System Controller (Without
Circuit Pack Cover)— ED6G999-31, G5 3-5
3-4 Low-Speed Shelf — System Controller (Without
Circuit Pack Cover) — ED6G999-32, G3 3-6
3-5 Interconnection Panel (Low-Speed Shelf —
System Controller) 3-12
3-6 Interconnection Panel (Low-Speed Shelf —
System Controller) —ED6G999-32, G3 3-13
3-7 User Panel (Enhanced) 6G999-31, G5 3-14
3-8 User Panel 6G999-32, G3 3-15
3-9 Low-Speed Shelf — System Controller
(with Covers) 3-16
3-10 High-Speed Shelf (Without Circuit Pack Cover) 3-18
3-11 Interconnection Panel (High-Speed Shelf) 3-20
3-12 Filter Panel (High-Speed Shelf and Enhanced
High-Speed Shelf) 3-22
3-13 High-Speed Shelf (with Covers) 3-23
3-14 Enhanced High-Speed Shelf (Without Circuit Pack
Cover) 3-26
3-15 Interconnection Panel (Enhanced High-Speed
Shelf) 3-28
3-16 Enhanced High-Speed Shelf (with Covers) 3-30
3-17 FT-2000 OC-48 Repeater Bay 3-33
3-18 FT-2000 OC-48 Repeater Shelf (Miscellaneously
Mounted) 3-34
