Working in manual mode
4.4 Positioning axes
Turning
116 Operating Manual, 01/2015, 6FC5398-8CP40-5BA2
4.4
Positioning axes
In order to implement simple machining sequences, you can traverse the axes to certain
positions in manual mode.
The feedrate / rapid traverse override is active during traversing.
Procedure
1.
If required, select a tool.
2.
Select the "JOG" operating mode.
3.
Press the "Positions" softkey.
4.
Enter the target position or target angle for the axis or axes to be tra
v-
ersed.
5.
Specify the desired value for the feedrate F.
- OR -
Press the "Rapid traverse" softkey.
The rapid traverse is displayed in field "F".
6.
Press the <CYCLE START> key.
The axis is tr
aversed to the specified target position.
If target positions were specified for several axes, the axes are tra
v-
ersed simultaneously.

Siemens SINUMERIK 828D Specifications

General

Control Type	CNC
Operating System	Windows Embedded
Processor	Intel Atom
Display	10.4" color TFT display
Interfaces	Ethernet, USB
Programming	ShopMill, ShopTurn
Operation Panel Size	10.4"
Protection Class	IP65
PLC Memory	2 MB
Spindle Capacity	4 spindles
Hard Drive	CompactFlash
