20.5 Displaying measured curves
Turning
Operating Manual, 01/2015, 6FC5398-8CP40-5BA2
863
20.5
Displaying measured curves
You can display current or saved measurement curves graphically or as detailed tables.
Display
Meaning
Start of the measurement Shows the time at which the measurement was started by pressing the
"Start measurement" softkey.
Duration of the measure-
ment [s]
Shows the measurement duration in seconds until the "Stop measure-
ment" softkey is pressed.
Device Displays the selected measured component.
• Manually
• Total, drives
• Total, machine
Supplied energy [kWh] Shows the supplied energy of the selected measured component in kilo-
watts per hour.
Regenerated energy
[kWh]
Shows the regenerated energy of the selected measured component in
kilowatts per hour.
Energy totals [kWh] Shows the total of all measured drive values or the total of all axes as
well as fixed value and Sentron PAC.
Display in the "Ctrl-E Analysis" window.
Procedure
1.
The "Ctrl
-E Analysis" window is open and you have already performed
and saved m
easurements.
2.
Press the "Graphic" and "Saved measurements" softkeys.
The measurement curves are displayed in the "Ctrl
-E Analysis" window.
3.
Press the "Saved measurements" softkey again if you only want to see
the actual measurement.
4.
Press the "Details" softkey to display the exact measurement data and
consumption values of the last three saved measurements and possibly
a current measurement.
