Ctrl-Energy
20.3 Measuring and saving the energy consumption
Turning
860 Operating Manual, 01/2015, 6FC5398-8CP40-5BA2
Measuring and saving the energy consumption
For the currently selected axes, you have the option of measuring and recording the energy
consumption.
Measurement of the energy consumption by part programs
The energy consumption of part programs can be measured. Single drives are taken into
account for the measurement.
They specify in which channel the start and stop of the part program should be initiated and
which number of repetitions are to be measured.
Save the measured consumption values so that you can subsequently compare the data.
Note
Up to three data records are displayed. The oldest data record is automatically overwritten if
there are more than three measurements.
The measurement duration is limited. When the maximum measurement duration is reached,
the measurement is terminated and a corresponding message is output in the dialog line.
Please refer to the machine manufacturer's specifications.
