Tool management
12.5 Tool list
Turning
Operating Manual, 01/2015, 6FC5398-8CP40-5BA2
687
Managing several cutting edges
In the case of tools with more than one cutting edge, a separate set of offset data is
assigned to each cutting edge. The number of possible cutting edges depends on the control
configuration.
Tool cutting edges that are not required can be deleted.
Position the cursor on the tool for which you would like to store more
cutting edges.
Press the "Cutting edges" softkey in the "Tool list".
Press the "New cutting edge" softkey.
A new data set is stored in the list.
The cutting edge number is incremented by 1 and the offset data is
assigned the values of the c
utting edge on which the cursor is posi-
Enter the offset data for the second cutting edge.
Repeat this process if you wish to create more tool edge offset data.
Position the cursor on the cutting edge that you want to delete and
press the "Delete cutting edge" softkey.
The data set is deleted from the list. The first tool cu
tting edge cannot
Tools that are no longer in use can be deleted from the tool list for a clearer overview.
Place the cursor on the tool that you would like to delete.
Press the "Delete tool" softkey.
A safety prompt is displayed.
Press the "OK" softkey if you really want to delete the tool.
Use this softkey to delete the tool.
If the tool is in a magazine location, it is unloaded and then deleted.
