Working with Manual Machine
15.7 Simulation and simultaneous recording
Turning
820 Operating Manual, 01/2015, 6FC5398-8CP40-5BA2
The parameters of the input screen forms correspond to the parameters under Automatic
(see Section "Milling (Page 431)").
Simulation and simultaneous recording
For more complex machining processes, you can check the result of your inputs with the aid
of the simulation, without having to traverse the axes (see Section "Simulating machining
(Page 195)"). The execution of the work steps is graphically displayed on the screen during
this period.
on "Simultaneous recording ShopTurn (real-time simula-
tion)" for the simultaneous recording of the work steps.
Note
In "Manual Machine", you can simulate a work step with an already opened and filled out
parameter screen form.
For the graphical display, a pre-defined blank shape is used. Just the same as under
simultaneous recording, in automatic and simulation you can change the blank as required
(see Section "Blank display (Page 206)").
