Creating a G code program
7.9 Calling technology cycles
Turning
Operating Manual, 01/2015, 6FC5398-8CP40-5BA2
233
You have called the desired cycle via softkey in the program editor, entered the parameters
and confirmed with "Accept".
Select the desired cycle call and press t
he <Cursor right> key.
The associated input screen of the selected cycle call is opened.
Press the <SHIFT + INSERT> key combination.
This starts the edit mode for this cycle ca
ll and you can edit it like a
normal NC block. This means that it is possible to generate an empty
block before the cycle is called. For instance, to insert something before
a cycle that is located at the beginning of the program.
Note: In edit mode, the c
ycle call can be changed in such a way that it
can no longer be recompiled in the parameter screen.
You exit the edit mode by pressing the <SHIFT + INSERT> key comb
i-
OR -
You are in the edit mode and press the <INPUT> key.
A new line is created after the cursor posi
tion.
Generating a G code program (Page 221)
Compatibility for cycle support
The cycle support is generally upwards compatible. This means that cycle calls in NC
programs can always be recompiled with a higher software version, changed and then run
again.
When transferring NC programs to a machine with a lower software version, it cannot be
guaranteed, however, that the program will be able to be changed by recompiling cycle calls.
