Programming technology functions (cycles)
9.4 Milling
Turning
482 Operating Manual, 01/2015, 6FC5398-8CP40-5BA2
The following parameters are hidden. They are pre-assigned fixed values or values that can
be adjusted using setting data.
PL (only for G code) Machining plane
SC (only for G code) Safety clearance 1 mm x
Reference point (only for G
Position of the reference point: Center
Machining
position (only for G code)
Mill slot at the programmed position (X0, Y0, Z0) Single posi-
Please refer to the machine manufacturer's specifications.
Circumferential groove (SLOT2)
Function
You can mill one or several circumferential slots of equal size on a full or pitch circle with the
"circumferential slot" cycle.
Please note that there is a minimum size for the milling cutter used to machine the
circumferential slot:
● Roughing:
1⁄2 groove width W – finishing allowance UXY ≤ milling cutter diameter
● Finishing:
1⁄2 groove width W ≤ milling cutter diameter
● Edge finishing:
Finishing allowance UXY ≤ milling cutter diameter
To create an annular groove, you must enter the following values for the "Number N" and
"Aperture angle α1" parameters:
N = 1
α1 = 360°
