Multi-channel machining
10.2 Multi-channel support
Turning
Operating Manual, 01/2015, 6FC5398-8CP40-5BA2
651
Display/edit the multi-channel functionality in the "Machine" operating area
10.2.12.1
You have various options to run-in programs.
Running-in channel-by-channel
Select the channels that you wish to process using the "Running-in" function in the "Program
control" window. The channels not selected here are brought into the "Program test (PRT)"
state. As a consequence, the channels are only calculated, but are not processed.
No M and auxiliary functions or tool functions are output. Spindle commands are only output
for selected spindles.
Running-in spindle-by-spindle
Only machining operations are executed for the spindle selected under program control /
running-in. When programming, using the block formation, allocate the corresponding
machining operations to a spindle.
When generating a block, a complete block can be assigned to a spindle. For the case that
the block is not executed, as the specified spindle should not be considered when running in,
then it is possible to temporarily activate what is known as an "Addit. run-in code".
You require the "programSYNC" option for cross
-channel program control.
● Multi-channel machine
● You have selected the multi-channel view via "Settings for channel functionalities".
Select the "AUTO" operating area.
Press the "Prog. ctrl." softkey.
- General" window appears on the screen.
"Run-in" softkey.
- Running-in" window is displayed.
Select the channels and the associated spindles to run-in the program.
