Programming technology functions (cycles)
9.1 Drilling
Turning
Operating Manual, 01/2015, 6FC5398-8CP40-5BA2
303
Boring (CYCLE86)
Function
With the "Boring" cycle, the tool approaches the programmed position in rapid traverse,
allowing for the retraction plane and safety clearance. It is then inserted into the workpiece at
the feedrate programmed under F until it reaches the programmed depth (Z1). There is an
oriented spindle stop with the SPOS command. After the dwell time has elapsed, the tool is
retracted either with or without lift of the tool.
Note
If, for example, swiveling
or mirroring has been performed with CYCLE800 before
machining, the SPOS command must be adapted so that the spindle position acts
synchronously with DX and DY.
For ShopTurn, the "Clamp spindle" function can be set up by the machine manufacturer.
Please refer to the machine manufacturer's specification
s.
When lifting, define the amount of lift D and the tool orientation angle α.
Note
The "Boring" cycle can be used if the spindle to be used for the boring operation is
technically able to go into position
-controlled spindle operation.
Clamping the spindle (Page 247)
