Programming technology functions (cycles)
9.1 Drilling
Turning
304 Operating Manual, 01/2015, 6FC5398-8CP40-5BA2
1. The tool moves with G0 to safety clearance of the reference point.
2. Travel to the final drilling depth with G1 and the speed and feedrate programmed before
the cycle call.
3. Dwell time at final drilling depth.
4. Oriented spindle hold at the spindle position programmed under SPOS.
5. With the "Lift" selection, the cutting edge retracts from the hole edge with G0 in up to
three axes.
6. Retraction with G0 to the safety clearance of the reference point.
7. Retraction to retraction plane with G0 to drilling position in the two axes of the plane
(coordinates of the hole center point).
or ShopTurn program to be processed has been cre-
ated and you are in the editor.
he "Drilling" softkey.
Press the softkey "Boring" for G code.
Press the softkeys "Drilling Reaming" and "Boring" for ShopTurn
The "Boring" input window opens.
Parameters, G code program
Parameters, ShopTurn program
PL
Machining plane T Tool name
SC Safety clearance mm F
Feedrate mm/min
mm/rev
S / V
Spindle speed or constant cut-
ting rate
rpm
m/min
