Teaching in a program
18.4 Teach-in via Windows
Turning
842 Operating Manual, 01/2015, 6FC5398-8CP40-5BA2
7.
Traverse the axes to the relevant position.
8.
Press the "Accept" softkey.
A new program block will be inserted at the cursor position.
- OR -
Press the "Cancel" softkey to cancel your input.
18.4.2
Teach in rapid traverse G0
You traverse the axes and teach-in a rapid traverse block with the approached positions.
Note
Selection of axes and parameters for teach-in
You can select the axes to be included in the teach
-in block in the "Settings" window.
You also specify here whether motion and tra
nsition parameters are offered for teach-in.
18.4.3
Teach in straight G1
You traverse the axes and teach-in a machining block (G1) with the approached positions.
Note
Selection of axes and parameters for teach-in
You can
select the axes to be included in the teach-in block in the "Settings" window.
You also specify here whether motion and transition parameters are offered for teach
-in.
