Working with Manual Machine
15.5 Simple workpiece machining
Turning
808 Operating Manual, 01/2015, 6FC5398-8CP40-5BA2
Simple workpiece machining
In "Manual Machine", you machine workpieces directly without creating a program.
The following functions are available to you for machining in manual mode:
● Axis movements
● Taper turning
● Straight (face and longitudinal turning) and circle
Note
Tool, spindle speed and direction of spindle rotation are activated with <CYCLE START>.
A change in feedrate immediately becomes active.
For preparatory actions and simple traversing movements, input the parameters directly into
the "Manual Machine" input fields of the basic screen.
"Manual Machine" is active.
Select the desired tool in "T".
Enter the feedrate (F) and the spindle speed (S).
Select the direction of spindle rotation (e.g. clockwise direction of rot
a-
:
Set the direction of rotation via the machine control panel.
Press the <CYCLE START> key.
The spindle starts immediately after the tool is selected.
Please refer to the machine manufacturer's specifications.
