Machining the workpiece
5.4 Displaying the current program block
Turning
126 Operating Manual, 01/2015, 6FC5398-8CP40-5BA2
Displaying the current program block
5.4.1
The window of the current block display shows you the program blocks currently being
executed.
Display of current program
The following information is displayed in the running program:
● The workpiece name or program name is entered in the title row.
● The program block which is just being processed appears colored.
Editing a program directly
In the Reset state, you can edit the current program directly.
Place the cursor at the relevant position and edit the program block.
Direct editing is only possible for G code blocks in the NC memory,
not
Press the <INSERT> key to exit the program and the edit mode
again.
If you want precise information about axis positions and important G functions during testing
or program execution, you can call up the basic block display. This is how you can check,
when using cycles, for example, whether the machine is actually traversing.
Positions programmed by means of variables or R parameters are resolved in the basic
block display and replaced by the variable value.
You can use the basic block display both in test mode and when machining the workpiece on
the machine. All G code commands that initiate a function on the machine are displayed in
the "Basic Blocks" window for the currently active program block:
● Absolute axis positions
● G functions for the first G group
● Other modal G functions
● Other programmed addresses
● M functions
