18.7 Deleting a block

Turning

Operating Manual, 01/2015, 6FC5398-8CP40-5BA2

847

18.7

Deleting a block

You have the option of deleting a program block entirely.

Requirement

"AUTO" mode: The program to be processed is selected.

Procedure

Select the "Machine" operating area.

Press the <AUTO> or <MDA> key.

Press the <TEACH IN> key.

Press the "Teach prog." softkey.

Click the program block to be deleted.

Press the ">>" and "Delete block" so

ftkeys.

The program block on which the cursor is positioned is deleted.
