Siemens SINUMERIK 828D User Manual

Tool management
12.15 Working with multitool
Turning
726 Operating Manual, 01/2015, 6FC5398-8CP40-5BA2
12.15.6
Loading and unloading multitool
Procedure
1.
The tool list is opened.
Load a multitool into the magazine
2.
Position the cursor at the multitool th
at you wish to load into the
magazine.
3.
Press the "Load" softkey.
The "Load to" window o
pens.
The "... location" field is pre
-assigned with the number of the first
empty magazine location.
4.
Press the "OK" softkey to load the multitool to the recommended
empty location.
- OR -
Enter the location number you require and press the "OK" softkey.
The multitool together with the tools in it is loaded to the specified
magazine location.
Loading a multitool into a magazine
2.
Position the cursor on the required empty magazine location.
3.
Press the "Load" softkey.
The "Load with." window opens.
4.
Select the required multitool.
5.
Press the "OK" softkey.
Unloading a multitool
2.
Position the cursor on the multitool that you wish to unload from
the magazine.
3.
Press the "Unload" softkey.
The multitool is removed from the magazine and is saved in the
NC memory at the end of the tool list.
