Managing programs
13.2 Opening and closing the program
Turning
738 Operating Manual, 01/2015, 6FC5398-8CP40-5BA2
Opening and closing the program
To view a program in more detail or modify it, open the program in the editor.
With programs that are in the NCK memory, navigation is already possible when opening.
The program blocks can only be edited when the program has been opened completely. You
can follow the opening of the program in the dialog line.
With programs that are opened via local network, USB FlashDrive or network connections,
navigation is only possible when the program has been opened completely. A progress
message box is displayed when opening the program.
Note
Channel changeover in the editor
When opening the program, the editor is opened for the currently se
lected channel. This
channel is used to simulate the program.
If you change over a channel in the editor, this does not influence the editor. Only when
closing the editor do you change into the other channel.
Select the "Program manager" operating area.
Select the desired storage location and position the cursor on the pr
o-
gram that you would like to edit.
Press the "Open" softkey.
Press the <Cursor right> key.
Double-click the program.
The selected program is opened in the "Editor" operating area.
Now make the necessary program changes.
Press the "NC Select" softkey to switch to the "Machine" operating area
and
begin execution.
When the program is running, the softkey is deactivated.
