Machining the workpiece

5.11 Display and edit user variables

Turning

Operating Manual, 01/2015, 6FC5398-8CP40-5BA2

159

Press t

he "GUD selection" softkey and the "SGUD" to "GUD6" softkeys

if you wish to display SGUD, MGUD, UGUD as well as GUD4 to GUD 6

of the global user variables.

- OR -

Press the "GUD selection" and ">>" softkeys as well as the "GUD7" to

"GUD9" softkeys if you want to displa

y GUD 7 to GUD 9 of the global

user variables.

Note

After each start

-up, a list with the defined UGUD variables is displayed in the "Global User

Variables" window.

5.11.4

Displaying channel GUDs

Channel-specific user variables

Like the GUDs, channel-specific user variables are applicable in all programs for each

channel. However, unlike GUDs, they have specific values.

Definition

A channel-specific GUD variable is defined with the following:

● Keyword DEF

● Range of validity CHAN

● Data type

● Variable names

● Value assignment (optional)

Example

DEF CHAN REAL X_POS = 100.5
