Siemens SINUMERIK 828D User Manual

Machining the workpiece
5.16 Working with DXF files
Turning
Operating Manual, 01/2015, 6FC5398-8CP40-5BA2
183
5.16.2.3
Enlarging or reducing the CAD drawing
Precondition
The DXF file is opened in the Program Manager.
Procedure
Press the "Details" and "Zoom +" softkeys if you wish to enlarge the size
of the segment.
- OR -
Press the "Details" and "Zoom
-" softkeys if you wish to reduce the size
of the segment.
- OR -
Press the "Details" and "Auto zoom" softkeys if you wish to automatically
adapt the segment to the size of the window.
5.16.2.4
Modifying the section
If you want to move or change the size of a section of the drawing, for example, to view
details or redisplay the complete drawing later, use the magnifying glass.
You can use the magnifying glass to determine the section and then change its size.
Precondition
The DXF file is opened in the Program Manager or in the editor.
