Edit PLC user program (828D only)

24.11 Editing block properties subsequently

Turning

898 Operating Manual, 01/2015, 6FC5398-8CP40-5BA2

24.11

Editing block properties subsequently

You can edit the title, author and comments of an INT block.

Note

You cannot edit t

he block name, subprogram number and data class assignment.

Procedure

The ladder diagram display is opened.

Select the relevant block and press the "Program block" softkey.

Press the "Properties" softkey.

The "Properties" window appears.
