Circle or pitch circle position pattern (HOLES2)
Function
You can program holes on a full circle or a pitch circle of a defined radius with the "Circle
position pattern" and "Pitch circle position pattern" functions. The basic angle of rotation (α0)
for the 1st position is relative to the X axis. The control calculates the angle of the next hole
position as a function of the total number of holes. The angle it calculates is identical for all
positions.
The tool can approach the next position along a linear or circular path.
Procedure
1.
The part program or ShopTurn program to be processed has been cr
e-
ated and you are in the ed
itor.
2.
Press the "Drilling" softkey.
3.
Press the "Positions" softkey.
4.
Press the "Circle" softkey.
- OR -
Press the "Pitch circle" softkey.
The "Position circle" or "Position pitch circle" input window is opened.
Parameters - "Circle" position pattern
Parameter
Description
Unit
LAB
(only for G code)
Repeat jump label for position
PL
(only for G code)
Machining plane
Axes
(only for G code)
Selection of the participating axes:
• XY (1st and 2nd axis of the plane)
• ZC (rotary axis and assigned linear axis)
Note
:
Rotary axes are only displayed in the selection field if they have been re-
leased for use in the position pattern.
Please observe the information provided by your machine manufacturer.
